Water Proof Watch Pressure Tester

1
MOQ
Water Proof Watch Pressure Tester
fitur Galeri Deskripsi Produk Quote request suatu
fitur
Spesifikasi
Dimensi internal: L1000×T1000×D1000 mm
Dimensi eksternal: L1600×T1950×D1450 mm
Berat: 400kg
Sakelar udara: 63A
Catu Daya: AC220V 50/60Hz
Volume: 1000 L
Suhu air: Suhu lingkungan atau (RT+15 Deg C) ~ 70 Deg C (Opsional)
jumlah tetesan IPX1: 1,0+0,5mm/menit
Durasi pengujian IPX1: 10 menit
jumlah tetesan IPX2: 3,0+0,5mm/menit
Durasi pengujian IPX2: 4 * 2,5 menit, 10 menit
Aliran air IPX3: 1,12 ~ 2,50L/mnt
Aliran air IPX4: 1,61 ~ 2,50L/mnt
aliran air IPX5: 12,5L/menit
aliran air IPX6: 100l/mnt
Menyoroti:

waterproof watch pressure tester

,

watch pressure test chamber

,

waterproof watch testing equipment
Informasi dasar
Tempat asal: Guangdong, Tiongkok
Nama merek: ASLI
Sertifikasi: CE,Third party calibration qualification report
Nomor model: RT-1000A
Syarat-syarat pembayaran & pengiriman
Deskripsi Produk
Water Proof Watch Pressure Tester
The Water Resistance Chamber is designed to test the waterproof effectiveness of electronic devices, automotive components, and communication equipment. It simulates rainfall conditions to evaluate waterproof performance and classify performance degradation.
Main Technical Parameters
Model RT-1000A
Specimens Flammable, explosive, or volatile material samples. Prohibited for corrosive substances, biological tests, and strong electromagnetic emission sources.
Volume 1000 L
Inner Dimension W1000×H1000×D1000 mm
External Dimension W1600×H1950×D1450 mm
Weight 400kg
Air Switch 63A
Power Supply AC220V 50/60HZ Single Phase Three Lines 6 m² Copper Wire
Performance Specification
Using Environmental Temperature: 5~30°C, Humidity <85% R.H. (Without load)
Water Temperature 1. Environmental temperature (uncontrolled)
2. Optional: (RT+15°C) ~ 70°C
IPX Testing Specifications
  • IPX1: Vertical drop water test - 1r/min rotation, ≤200mm distance, 1.0±0.5mm/min droplets, 10min duration
  • IPX2: 15° tilt drop test - four positions tested, 3.0±0.5mm/min droplets, 10min total duration
  • IPX3: 400mm swinging radius, 1.12-2.50L/min flow, 16 holes (0.4mm), 10min test with 90° rotation at 5min
  • IPX4: 400mm swing pipe, 1.61-2.50L/min flow, 23 holes (0.4mm)
  • IPX5: 12.5L/min flow, 6.3mm holes, ≥3min test
  • IPX6: 100L/min flow, 12.5mm holes, ≥3min test
Compliance Standards
JIS-D0203, IEC-60529, GB/T 2423.38 2006, IEC 60068-2.18:2000, GB4208-2008, IEC60529-2001
Water Proof Watch Pressure Tester 0 Water Proof Watch Pressure Tester 1
For any questions or requirements regarding the Water Proof Watch Pressure Tester, please don't hesitate to contact us.
